Windom 3,5-7-14-28 LP
Code: 43/CU-2 43/CU-3 Choose variantProduct detailed description
Windom antenna (OCF, FD-4) for bands 3,5-7-14-28 MHz. CLASSIC LP version
Mounting for hanging by unun.
Suspension by the ends of the arms only possible with the CU-HD version.
Specifications:
- bands 3,5-7-14-28 MHz
- arm length approx. 14+28 m (tuning by arm length)
- antenna wire according to variant - CU-PVC, CU-PE, CU-HD
- unun 1:6
- 50 ohm coaxial cable feed
- power load 300 W (on digi, FT8 etc. max 100 W)
- weight 0,8 kg (with CU-PVC wire)
- attachment for hanging
- PL (UHF) connector
